Three-piece stainless steel ball valve ith full bore and flanged ends -  V - 005 FML PN 40


Application
Shut-off valve for aggressive and non-
aggressive liquids, gases and loose media
mainly in food and chemical industries for
service pressures up to PN 40 and
temperatures from -50°C to 230°C. It is
suitable also for service where contamination
of service medium by corrosive products is
undesirable. Service medium can flow in both
directions. The valve is not suitable for flow
regulation.

Connection
Basic connecting and face-to-face dimensions
are given in the table below.

Installation
The valve can be installed into vertical or
horizontal piping.

Operation
The valve is operated by a lever turning
by 90°.
